With mioXM™ it’s never been easier to get all of your MIDI gear talking to each other. Harness the power of iConnectivity advanced computer and network connectivity and experience why mioXM redefines what a MIDI interface can and should do.

Connect all your MIDI devices (USB-MIDI, DIN-MIDI, RTP/Network-MIDI) and let this rugged, versatile interface put you in control of your MIDI devices and workflow.

On stage or in the studio, RTP/Network-MIDI capability means you are no longer constrained by cable length or limited USB ports. Stack multiple interfaces and computers on a network for ultimate scalability and flexibility.

With mioXM, you’re able to streamline and expand your MIDI setup, and do it faster, better, and in creative and exciting new ways.

Features:

• 4 in x 4 out 5-pin DIN-MIDI ports
• 4x USB-MIDI Host ports support multiple USB-MIDI class compliant devices
• Ethernet RTP-MIDI Network port - 12 virtual network ports can easily be assigned to onboard DIN and USB ports as well as any other connected computing devices. These make all MIDI devices accessible to Mac, PC, and mobile computing devices via a single cable.
• Connect multiple computers via expandable virtual network ports
• USB Computer port supporting Mac & Windows connectivity
• Plug and Play - no drivers required thanks to class compliant connectivity
• Capacitive touch control panel
• Up to four user-definable presets can be stored and recalled from mioXM’s control panel
• iConnectivity’s Auracle 2.0™ configuration software (downloadable for Mac & Windows) makes it simple to create and save filtering/routing/merging presets
• Connect iOS devices via CCK to mioXM’s USB device port, Wi-Fi (using 3rd party Wi-Fi ethernet hub), or wired ethernet connections
• Includes: mioXM, USB Cable, Ethernet Cable, mioXM 12V 36W Power Power Supply
• System Requirements: Mac OS X 10.13 or later, Windows 10 or later, iOS 8 or later, CoreMIDI compatible app, Android 8.0 or higher with USB-C connector
• Dimensions: 8.43" (W) x 5.51" (D) x 1.46" (H) / 214mm (W) x 140mm (D) x 37mm (H)
• Weight: 992 g / 2.13 lbs
